Rückansicht des Netgate 1541 Netzwerksicherheitsgeräts mit Anschlüssen und Belüftungsöffnungen
Rückansicht des Netgate 1541 Netzwerk-Sicherheitsgeräts mit mehreren Ethernet-Ports und USB-Anschlüssen.

Netgate 1541

Sale price€3.049,00 EUR

Tax excluded. Shipping calculated at checkout

Your advantage : No customs duties and no import tax within the EU.

The hardware includes the latest version of pfSense+ (preinstalled).

Netgate 1541

Memory: 16GB RAM + 500GB M.2 SSD Storage (Base)
Netgate support: TAC Lite (Free)
Initial setup of LanCologne: Without configuration
In stock
✆ Questions? Chat on WhatsApp now

The Netgate® 1541 Security Gateway with pfSense® Plus software is our most powerful solution for medium to large enterprise data centers or server rooms. It features a 2.1 GHz, 8-core, 16-thread Intel® Xeon® D-1541 processor with AES-NI, two 10GBase-T ports and two 1 Gbps RJ-45 ports. The CPIC-8955 cryptography accelerator cardwithQAT (QuickAssist Technology) can be added to offload encryption processing for improved VPN throughput performance. Other expansion options include a 2- or 4-port Intel 10 GbE card for additional SFP+ ports or a 4-port Intel 1 GbE card for additional RJ45 ports. With RAID configurations and high availability options, the Netgate 1541 is our most robust solution for high throughput and/or mission critical deployment requirements.

Equipped with an Eight Core Intel Xeon® 2.1 GHz, upgradeable memory up to 32 GB and expandable network interfaces up to (8) ports, the Netgate 1541 achieves routing performance of up to 18.8 Gbps.

L3 Forwarding

  • IPERF3 traffic: 18.8 Gbps
  • IMIX traffic: 15.1 Gbps

Firewall

(10k ACLs)

  • IPERF3 traffic: 18.64 Gbps
  • IMIX traffic: 12.3 Gbps

IPsec VPN

(AES-GCM-128 w/QAT)

  • IPERF3 traffic: 9.30 Gbps
  • IMIX traffic: 1.77 Gbps

Netgate 1541 performance tests performed with pfSense plus software version 22.01

CPU: Eight Core Intel Xeon® 2.1 GHz, with AES-NI compatibility, significantly improves encrypted throughput and increases RAM performance by up to 50%.

Network ports: The Netgate 1541 is expandable up to 8 network ports and offers (2) 10GBase-T LAN/WAN over SoC, (2) 1GbE LAN/WAN over Intel i350-AM2 and support for a 4-port Intel 1GbE expansion card or a 2-port or 4-port Intel 10GbE SFP+ expansion card X710.

Storage: 500 GB M.2 SSD

Memory: 16 GB DDR4 (expandable to 32 G ECC), DDR4 memory enables more stable, higher transfer rates for memory-intensive applications (e.g. IDS/IPS). Our hardware flexibility allows you to upgrade your memory to 32 GB at any time, future-proofing this appliance.

pfSense Plus software delivers the performance, flexibility, reliability and business security expected from leading secure network applications:

  • Up to 10 Gbit/s performance
  • Flexible options for third-party applications
  • Traditional management mechanisms
  • Proven reliability
  • Comprehensive support for securing business

At a fraction of the cost of proprietary alternatives, pfSense Plus software is the perfect answer. Popular use cases for pfSense Plus include load balancing, traffic shaping, captive portal, UTM device, DNS/DHCP server, IDS/IPS, transparency caching proxy, web content filtering, failover WAN and more.

Technical specifications

Here you will find the most important technical data about the product. If you have any questions, you can always contact our customer service.

CPU

Intel "Xeon-DE" D-1541, FCBGA 1667 supports SoC AES/NI and Intel QuickAssist

CPU cores

8 cores, 45W

network

2x 1GB LAN via Intel® i350-AM2 1 Gigabit Ethernet 2x 10GB LAN via SoC 10GBase-T 1 Dedicated IMPI Lan port. Expandable

Storage

150GB SSD

R.A.M.

16GB DDR4 UDIMM

extension

Extension 1x PCI-E 3.0 x 16 (in x4) AOC Slot 6x SATA3 ports

console port

1x BMC integrated ASPEED AST2400
1x IPMI port
1x VGA port
2x Fast UART 16550 serial ports (1 rear, 1 header)

USB ports

2x USB 3.0 ports

LEDs

Power LED
Hard drive activity LED
2x network activity LEDs
System Overheat LED
Information LED (temp., status)

Other

form factor

Standard 19″ 1U rack mount

43.7cm x 4.32cm x 25cm (17.2″ x 1.7″ x 9.85″)

cooling

200W Low-noise PS with PFC: Active CPU fan, 40mm chassis fan

power adapter

1x SATA DOM power connector 100-240V, 50-60Hz, 2.6 Amp MAX German power cable IEC connector C13 power cable

Vicinity

10°C to 35°C Operating Temp
8% to 90% Operating Relative Humidity (non-condensing)

power consumption

TBD (idle)

certificates

FCC, CE, RoHS, UL

support

Netgate Support TAC Lite included
Netgate Support TAC Professional and TAC Enterprise can be added at additional cost
All support services are provided by Netgate USA.
LanCologne is only a reseller in selling the Service.

Advantages of the Netgate 1541

LOW TOTAL COST OF OWNERSHIP

  • No artificial restrictions or additional programs are required to make your system fully functional.
  • No additional usage or feature based pricing. Enjoy unlimited users, unlimited firewall rules, unlimited IPsec tunnels, dual WAN, etc.
  • Standard configuration with 16 GB RAM and 256 GB Micron M.2 SSD*.
  • Low power consumption to save you money.
  • This system is designed for a long period of use.

GROW WITH YOU

  • From firewalls to unified threat management, you get all the security features you need to protect your home or business.
  • Flexible configuration and support for multi-WAN, high availability, VPN, load balancing, reporting and monitoring, etc.
  • Add optional packages like Snort or Suricata for IDS/IPS and network security monitoring, Squid for optimized content delivery, and SquidGuard for anti-spam/anti-phishing and URL filtering . 1
  • Maximum active connections: 16,000,000 (32,000,000 with 32 GB RAM)

EASY MANAGEMENT VIA THE USER INTERFACE

  • Manage pfSense Plus software settings through our web-based GUI.
  • No fiddling with a command line interface or typing obscure commands.

SECURE REMOTE ACCESS

  • Connect between your offices via encrypted virtual private networks (VPN), let mobile workers connect securely, or connect to the cloud!
  • Use the built-in Amazon VPC wizard to easily establish VPN connections to your Amazon EC2 cloud.

BEST SUITED FOR:

  • Medium to large networks with 1U rack-mount cabinets
  • Medium to large branch offices with a high load
  • Managed Service Providers (MSP) / Managed Security Service Provider (MSSP) On-site Application
  • Company
  • Anyone with high-speed 10 Gigabit and/or 1 Gigabit connections.
  • Anyone with many VPN connections
  • People with high-speed connections who want to configure IDS/IPS functions

SOFTWARE FEATURES:

pfSense Plus software is a powerful firewall, router and VPN solution based on a number of highly regarded open source projects. The software effectively competes with far more expensive commercial alternatives and is used by hundreds of thousands of businesses, educational institutions and government agencies around the world. Leading features and capabilities for secure networking include:

  • Ad Blocker (pfBlockerNG)
  • Unencrypted portal
  • CARP / HA
  • DNS server
  • DHCP server
  • HTTP transparent / Web / Reverse Proxy (Squid)
  • IP / Country Block List (pfBlocker)
  • IDS/IPS
  • Package capture / inspection
  • Port forwarding
  • QOS / rate limiter
  • Software load balancer (HA proxy)
  • Traffic monitoring
  • Traffic logging, statistics and charts
  • Traffic design
  • VLAN
  • Wake-on-LAN
  • Website Blocker (pfBlocker)
